Model
Brand LSI
Series 9380
Model MegaRAID SAS 9380-8e (LSI00438)
Part LSI00438
Form Foctor Low Profile
Details
Type SAS
External Connectors 2 Mini-SAS HD SFF8644
Interface PCI-Express 3.0 x8
Transfer Rate Up to 12Gb/s
Cache Memory 1GB 1866MHz DDRIII SDRAM
RAID RAID 0/1/5/6/10/50/60
Dimensions MD2 Low profile (6.6" x 2.536")
Features
High performance 12Gb/s data transfer rates
Eight external 12Gb/s SATA+SAS ports
Two mini-SAS SFF8644 external connectors
LSISAS3108: 1.2GHz PowerPC 476 dual core 12Gb/s ROC
PCI Express 3.0 host interface
1GB DDRIII cache memory
RAID levels 0, 1, 5, 6, 10, 50, and 60
Support for CacheVault flash cache protection
Package Contents
MegaRAID SAS 9380-8e, QIG, LP bracket
