Model
Brand LSI
Series MegaRAID
Model LSI00330 (9271-8i)
Form Factor Low Profile
Details
Type SATA / SAS
Internal Connectors 2 x SFF-8087 mini-SAS
Interface PCI-Express 3.0 x8
Transfer Rate Up to 6Gb/s
Cache Memory 1GB 1333 MHz DDRIII SDRAM
RAID RAID 0/1/5/6/10/50/60
Dimensions MD2 Low profile (6.6" x 2.54")
Features
I/O Processor / SAS Controller: LSISAS2208 Dual-Core RAID on Chip (ROC)
Eight-port 6Gb/s PCI Express 3.0 SATA+SAS RAID controller
Second-generation 6Gb/s SATA+SAS controller, built on the LSISAS2208 dual-core ROC
Proven interoperability with the latest server platforms based on the PCI Express 3.0 specification
*Cables not included.
Package Contents
MegaRAID SAS 9271-8i RAID Controller (Single)
QIG
LP bracket
