Model
Brand LSI
Model LSI00301 (9207-8i)
Form Fctor Low Profile
Details
Type SATA / SAS
Internal Connectors 2 x SFF-8087 mini-SAS
Interface PCI-Express 3.0 x8
Transfer Rate Up to 6Gb/s
Dimensions Low Profile (2.6" x 6.6")
Features
IO Controller: LSI SAS2308, Fusion MPT 2.0
Cable Support: Passive Copper
PCI Card Type: 3.3 V Add-in Card
Operating Voltage: +12V +/- 8%; 3.3V +/- 8%
PCI Power (Nominal): 9.8W
Device Support: 256 Non-RAID devices.
