Model
Brand LSI
Model LSI00300 (9207-8e)
Form Factor Low Profile
Details
Type SATA / SAS
External Connectors 2 x SFF-8088 mini-SAS
Interface PCI-Express 3.0 x8
Transfer Rate Up to 6Gb/s
Dimensions Low Profile (2.6" x 6.6")
Features
IO Controller: LSISAS2308, Fusion MPT 2.0
Cable Support: Passive Copper, Active Copper
PCI Card Type: 3.3 V Add-in Card
Operating Voltage: +12V +/-8%; 3.3V +/-8%
PCI Power (Nominal): 9.8W
Device Support: 1024 Non-RAID SATA/SATA devices.
